Building and Power inspections

As construction industry professionals like a craftsman or a team member of a Public Works Group you can produce thermal readings, get an overview of the thermal losses of a facade or observe the condition of a structure. The drone offers cost-control benefits and removes the need for equipment such as ladders and scaffolding.
As energy suppliers and transporters, in just a few minutes you can identify a power failure on a high-voltage cable, or isolate a defective solar panel with a light and easy to implement solution.

Fireman assistance

As civil security experts, you can, remotely and post-intervention, monitor hot points and decide whether, according to the results observed, to retain a team or equipment on site. Whether using 4K images or thermal rendering, searching for people in rugged areas can be faster, without endangering the teams.
THERMAL IMAGING CAMERA TO REVEAL, MEASURE AND CAPTURE THE INVISIBLE
A FLIR Lepton 3.5 thermal-imaging camera module, a market-leading product, is integrated into ANAFI Thermal's gimbal. Each element of the environment appears in high precision, with visual representations of thermal leaks and temperature differences superimposed on
the image. It reveals the thermal differences of flyover areas and elements:
• Hot spots, cold spots, thermal leaks, etc.
• FLIR Lepton 3.5 microbolometer (radiometric)
• Precision of  ±5% max.(High-gain) or ±10% max.(Low-gain)
• Dynamic Range: -10° to +140°C (High-gain) or -10° to +400°C
(Low-gain)
4K CAMERA TO INSPECT, OBSERVE AND ANALYSE THE VISIBLE
ANAFI Thermal embeds the very best from the world of imaging using a 4K HDR camera with 21MP Sony sensor.You can accurately inspect a building, capture illustrative elements of the state of a structure or a search area for example, or carry out 3D modelling.
• Sony® CMOS HDR sensor 1/2.4’’ 21MP
• ASPH wide angle lens f/2.4
• 23-69mm (photo), 26-78mm (video) in 35mm equivalent
focal length
• Lossless zoom x2.8 (x3 in standard mode)
• Adobe DNG/RAW and P-LOG professional formats
Smart Battery 26 minflight time
WiFi connection up to 4km
Weighs only 315 g
Automaticreturn home (RTH)
Customisable geofence
Wind resistance 31 mph

Specifications

Weight:
315 g
Maximum transmission distance:
4km with the Parrot
  • Maximum flight time:
    26 min
    Maximum horizontal speed:
    34 mph
  • Maximum vertical speed:
    4m/s
  • Max. coverage at 2,000 m (6,500 ft):

    40 km2(15.4 mi2)

    Maximum wind resistance:
    31mph
    Maximum working altitude:
    4,500m above sea level
    Operating temperature:
    from -10°C to 40°C

    DIMENSIONS

    Folded:
    218x69x64mm
    Unfolded:
    241x315x64mm

    SENSORS

    GNSS:
    GPS + GLONASS
    Senser:
    Barometer and magnetometer
    Senser:
    Vertical camera and ultrasound sensor
    Senser:
    2x6-axis IMU
    Senser:
    2x3-axes accelerometer
    Senser:
    2x3-axes gyroscope
Sensor:
CMOS 1/2.4", 21MP
Video format:
MP4 (H264)
HDR:
4K UHD, 2.7K et 1080p videos, JPEG photos
Photo formats:
JPEG, DNG(RAW)
Photo modes:
single, burst, bracketing, timer and panoramaome text inside of a div block.
Shutter speed:
from 1 to 1/10000s
ISO:
from 100 to 3200
EV compensation:
[-3, +3]
Maximum video sampling rate:
100Mbps
LD-ASPH LENS :
f/2.4 aperture
Depth of focus
26mm (35mm equivalent)
Depth of field:
1.5m to infinity
Lossless:
up to x2.8 (FHD), up to x1.9 (2.7K), up to x1.4 (4K UHD)
Standard:
up to x3 (all resolutions)
Wide angle:
21MP (5344x4016) / 4:3 / 84° HFOV
Rectilinear:
16MP (4608x3456) / 4:3 / 75.5° HFOV
4K Cinema:
4096x2160 24fps
4K UHD:
3840x2160 24/25/30fps
FHD:
1920x1080 24/25/30/48/50/60fps
HD:
1280x720 48/50/60fps
HFOV video:
69°
Sensor:
FLIR Lepton 3.5 microbolometer (radiometric)
Sensor resolution:
160x120
HFOV:
57°
Pixel pitch:
12µm
Spectral band:
8-14µm
Thermal sensitivity:
<50mK (0.050°C)
Photo format:
JPEG
Photo resolution:
3264x2448 (4/3)
Photo modes:
Single / Time-lapse / GPS Lapse
Video format:
MP4 (H264)
Video recording resolution:
1440x1080, 9fps
Precision:
±5% max.(High-gain) or ±10% max.(Low-gain)
Scene Dynamic Range:
-10° to +140°C (High-gain) or -10° to +400°C (Low-gain)
Video:
MP4

Flight planning & control software (supplied):


eMotion 3

Image processing software (optional):

Pix4Dmapper, Pix4Dbim
